  1. © 2020, Amazon Web Services, Inc. or its affiliates. All

    rights reserved. Securing your Amazon ECS applications: Best practices Tori Hara Sr. Product Developer Advocate, Containers AWS C O N 2 1 2
  2. © 2020, Amazon Web Services, Inc. or its affiliates. All

    rights reserved. • Amazon Elastic Container Service (Amazon ECS) overview • Securing your Amazon ECS tasks • Operating your Amazon ECS tasks securely • Takeaways Agenda
  3. © 2020, Amazon Web Services, Inc. or its affiliates. All

    rights reserved. Amazon ECS overview
  4. What does ECS look like? Amazon ECS Amazon ECS users

    API calls to run containers Bring your own Amazon EC2 instances (and/or AWS Fargate–managed servers) EC2 instance Amazon ECS container agent Container runtime API calls to run containers Container Run Amazon ECR, Docker Hub, … API calls to download container images Logs Amazon CloudWatch Logs, Fluentd, … API calls to send container logs Elastic Load Balancing
  5. Amazon ECS constructs: Task and service Amazon ECS task Defined

    by a “task definition” A group of 1 or more containers The smallest deployable unit Configure networking, storage, parameters, IAM roles, and compute resources Similar to the docker run command on your local machine Amazon ECS service Defined by a “service definition” Enables you to run and maintain a required number of Amazon ECS tasks Automatically handles Amazon ECS task failures by replacing them with new Amazon ECS tasks Configure Amazon VPC networking, deployment type, optional load balancers, and service discovery
  6. Amazon ECS constructs: Cluster A logical grouping of Amazon ECS

    tasks or services in a region Multiple clusters can be created Clusters / services / tasks work as IAM permission boundaries ECS cluster ECS services ECS tasks
  7. © 2020, Amazon Web Services, Inc. or its affiliates. All

    rights reserved. Securing your Amazon ECS tasks
  8. Step 1: Security groups ECS service sg-ALB sg-ECSTask sg-AuroraDB Allowed

    type and port HTTPS: 443 HTTP: 80 MySQL/Aurora: 3306 Allowed source 0.0.0.0/0 (Public access) 10.0.0.0/16 (From within the VPC) 10.0.0.0/16 (From within the VPC)
  9. Step 1: Security groups ECS service sg-ALB sg-ECSTask sg-AuroraDB Allowed

    type and port HTTPS: 443 HTTP: 80 MySQL/Aurora: 3306 Allowed source 0.0.0.0/0 (Public access) sg-ALB (Only from the ALB) sg-ECSTask (Only from the ECS tasks)
  10. Step 2: Secrets ECS service { ... snip ... "containerDefinitions":[{

    "name":"my-web-app", "image":"my-web-app:v1", ... snip ... "environment": [{ "name": "DB_USER", "value": "myappdbuser" },{ "name": "DB_PASSWD", "value": "mysupersecretpasswd" },{ "name": "DB_HOST", "value": "my-db...rds.amazonaws.com" },{ "name": "DB_PORT", "value": "3306" }], ... snip ... }], ... snip ... } ECS task definition
  11. Step 2: Secrets ECS service { ... snip ... "containerDefinitions":[{

    "name":"my-app", "image":"my-web-app:v1", ... snip ... "secrets": [{ "name": "DB_USER", "valueFrom": ”...secretsmanager:...:my-db-secret:username::" },{ "name": "DB_PASSWD", "valueFrom": ”...secretsmanager:...:my-db-secret:password::" }], "environment": [{ "name": "DB_HOST", "value": ”my-db...rds.amazonaws.com" },{ "name": "DB_PORT", "value": ”3306" }] ... snip ... } ECS task definition AWS Secrets Manager Secrets injected by ECS at task runtime
  12. Step 3: ECS task-level IAM roles ECS service { ...

    snip ... "taskRoleArn": "", "executionRoleArn": "", "containerDefinitions":[{ ... snip ... }], ... snip ... } ECS task definition
  13. Step 3: EC2-level IAM role ECS service { "AttachedPolicies": [{

    "PolicyName": "AmazonS3FullAccess", "PolicyArn": "arn:aws:iam::aws:policy/AmazonS3FullAccess" }, { "PolicyName": "AmazonSQSFullAccess", "PolicyArn": "arn:aws:iam::aws:policy/AmazonSQSFullAccess" }, { "PolicyName": "AmazonEC2ContainerServiceforEC2Role", "PolicyArn": "arn:aws:iam::aws:policy/service- role/AmazonEC2ContainerServiceforEC2Role" }] } EC2 instance IAM role’s policies IAM role
  14. Step 3: EC2-level IAM role All ECS tasks on the

    same EC2 instance can use the EC2 instance role IAM role EC2 instance ECS task Another ECS task Really want to allow? ! !
  15. Step 3: IAM roles for tasks { ... snip ...

    "taskRoleArn": ”TaskRole-ARN-here", "executionRoleArn": "", "containerDefinitions":[{ ... snip ... }], ... snip ... } ECS task definition { "Version": "2012-10-17", "Statement": [{ "Effect": "Allow", "Action": ["s3:ListBucket"], "Resource": ["arn:aws:s3:::your-bucket"] },{ "Effect": "Allow", "Action": [ "s3:PutObject", "s3:GetObject", "s3:DeleteObject" ], "Resource": ["arn:aws:s3:::your-bucket/*"] }] } S3 write-only policy { "Version": "2012-10-17", "Statement": [{ "Effect": "Allow", "Action": "sqs:SendMessage", "Resource": "arn:aws:sqs:...:your-queue-name" }] } SQS write-only policy { "AttachedPolicies": [{ "PolicyName": "S3WriteOnlyPolicy", "PolicyArn": "S3WriteOnlyPolicy-ARN-here" },{ "PolicyName": "SQSWriteOnlyPolicy", "PolicyArn": "SQSWriteOnlyPolicy-ARN-here" }] } ECS task role
  16. Step 3: IAM roles for tasks 🚫 EC2 instance ECS

    task Another ECS task Denied IAM role
  17. Step 3: “Task Execution Role”? IAM role for task (task

    role) Task execution role EC2 instance Amazon ECS container agent Container runtime ECS task Amazon ECR registry Logs Amazon CloudWatch Logs AWS Secrets Manager EC2 instance Amazon ECS container agent Container runtime ECS task
  18. Step 4: Logs from apps Container runtime ECS task stdout

    stderr Amazon CloudWatch Logs { ... snip ... "containerDefinitions":[{ "name":"my-web-app", "image":"my-web-app:v1", ... snip ... "logConfiguration": { "logDriver": "awslogs", "options": { "awslogs-group": "/ecs/my-web-app", "awslogs-region": "us-west-2", "awslogs-stream-prefix": "ecs" }} }], ... snip ... } ECS task definition
  19. Step 4: Logs from apps Container runtime ECS task Logs

    CloudWatch Logs Amazon Kinesis Data Firehose Lambda function Lambda function Amazon Elasticsearch Service Kibana For “hot data” S3 bucket Amazon Athena For “cold data” Elasticsearch subscription filter Custom subscription filter https://docs.aws.amazon.com/AmazonECS/latest/developerguide/using_firelens.html
  20. 1. Immutable tags • Image tags can be overwritten by

    push • Use immutable tags to use expected container images at any given time 2. Image scanning • “Scan on push” for automatic scanning • Scheduled rescanning is also recommended to handle CVEs after image creation; see also https://aws.amazon.com/blogs/containers/am azon-ecr-native-container-image-scanning/ Step 5: Enabling ECR features
  21. Securing your Amazon ECS app • ECR immutable tags and

    image scanning • No privileged mode • Non–root user • Read-only file system • Security groups • Secrets • Task role and task execution role • Container logs https://docs.docker.com/develop/develop-images/dockerfile_best-practices/
  22. © 2020, Amazon Web Services, Inc. or its affiliates. All

    rights reserved. Operating your Amazon ECS tasks securely
  23. 1. Access-control for Amazon ECS resources 2. Auditing AWS API

    calls 3. Validating AWS resources to keep everything compliant Operating your Amazon ECS tasks securely
  24. Step 6: Access control Amazon ECS ECS users API calls

    { "Version": "2012-10-17", "Statement": [{ "Sid": ”ReadOnlyAccess", "Effect": "Allow", "Action": [ "ecs:DescribeCluster” ], "Resource": "arn:aws:ecs:region:account-id:cluster/our-cluster" }] } IAM policy
  25. Step 6: Access control Amazon ECS ECS users API calls

    { "Version": "2012-10-17", "Statement": [{ "Sid": ”ReadOnlyClusterResources", "Effect": "Allow", "Action": [ "ecs:Describe*", "ecs:List*" ], "Condition": { "ArnEquals": { "ecs:cluster": "arn:aws:ecs:region:account-id:cluster/our-cluster" } }, "Resource": "*" }] } IAM policy
  26. Step 6: Access control Amazon ECS ECS users API calls

    { "Version": "2012-10-17", "Statement": [{ "Sid": "ECSFullAccessIfOwner", "Effect": "Allow", "Action": "ecs:*", "Resource": "*", "Condition": { "StringEquals": { "ecs:ResourceTag/Owner": "${aws:PrincipalTag/Team}" } } }] } only if resource ”Owner” tag and user “Team” tag values match IAM Policy
  27. • AWS CloudTrail allows you to keep track of AWS

    API call events in your AWS account • Recorded events will have § eventTime § userIdentity § eventSource (represents an AWS service) § eventName (represents an API action name) § and more! Step 7: Audit AWS API calls Learn more: https://docs.aws.amazon.com/awscloudtrail/latest/userguide/ cloudtrail-event-reference-record-contents.html
  28. Step 7: Audit Amazon ECS API calls AWS CloudTrail S3

    bucket Amazon Athena Ad hoc auditing Regular analysis and auditing
  29. Use AWS Config to validate your configurations to be compliant

    • IAM resources can be automatically remediated • Amazon ECS is not officially supported by AWS Config yet • Write custom rules to validate Amazon ECS resources such as task definitions Step 8: Validate your resources For more examples, go to https://github.com/awslabs/aws-config-rules
  30. © 2020, Amazon Web Services, Inc. or its affiliates. All

    rights reserved. Steps to further secure workloads
  31. • Avoid manual operations, to process everything robustly and securely

    • CI/CD pipelines help automate building, testing, and deployment Automate everything Source Build Test Deploy Monitor Related session CON210 – Developing CI/CD pipelines with Amazon ECS and AWS Fargate
  32. Security benefits of AWS Fargate Related sessions CON203 – Choosing

    your container data plane on AWS CON216 – AWS Fargate: Are serverless containers right for you? AWS manages and patches hosts for you No privileged or SSH access Secure isolation boundaries
  33. Secure your Amazon ECS applications • Harden Amazon ECS tasks

    throughout their life cycles • Keep operations robust One step further • Automate everything as much as possible • Use AWS Fargate to harden your workloads with less effort Get started today • All Amazon ECS features covered today are available without installing any additional software Takeaways
  34. Thank you! © 2020, Amazon Web Services, Inc. or its

    affiliates. All rights reserved. Tori Hara toricls
